The SX10SR is engineered to provide users the ideal combination of power, speed, innovation, and proven performance they demand from Superwinch. Innovative features such as a patented drum light, relocatable die-cast aluminum control box, 3/8" diameter synthetic rope, a 12' lighted wired remote, and wireless handheld remote. SX Series winches exceed the most demanding standards of today's modern vehicles, while delivering an affordable and stylish design which incorporates many class leading features not found in other high-performance winches. Providing 10,000 lbs. of raw pulling power, the new SX10SR synthetic rope model has a sleek modern look and is built to last. With an IP68 rating for dustproof and waterproof operation, and a durable metallic graphite powder-coated finish this winch has it all.
SX10SR Winch; Black;
| Brand | Superwinch |
|---|---|
| Part Number | 1710204 |
| Can Ship By Ground Delivery | Yes |
| Clutch | Pull and turn clutch handle |
| Color | Black |
| Control Box | Relocatable Die-Cast Aluminum |
| Drum | Durable fully welded steel drum |
| Fairlead | Aluminum hawse |
| Finish | Powder Coated |
| Gear Ratio | 218:1 |
| Gear System | 3-stage planetary |
| IP Rating | IP68 Waterproof and Dustproof |
| Material | Steel |
| Motor | 5.5 HP, 12V DC |
| Mounting Bolt Pattern | 10in x 4.5in (254mm x 114.3mm) |
| Mounting Hardware Included | Yes |
| Mounting Type | Bolt-On |
| Rated Single Line Pull (Lbs) | 10000 |
| Remote Type | Wire and Wireless |
| Rope Length | 3/8 in x 80 ft (9.5mm x 24.3m) |
| Rope Material | Synthetic |
| Task Lighting | Patented drum light |
| Voltage | 12V DC |
| Winch Hook | Heavy-Duty, Clevis Pinned Latched |
| Winch Model | SX10SR |
| Winch Series | SX Series |
| Brake System | 100% Full-load holding automatic mechanical brake |
| Dimensions | 22.04in L x 6.3in W x 9.67in H (559.8mm L x 160.02mm W x 245.62mm H) |
| Line Speed | 0 lbs. - 85 Amps Motor Draw/27.3 FPM (8.32 MPM) | 10000 lbs. - 363 Amps Motor Draw/4.5 FPM (1.37 MPM) |
| Remote Control | Wireless hand-held remote & 12 ft handheld wired remote included (wired remote features flashlight with built-in lithium ION battery. Recharges while plugged into winch.) |
| Warranty | Limited Lifetime Mechanical/7 Year Limited Electrical |
| Weight | 61 lbs |
| Drilling Required | No |
| EN Compliant | No |
