Meet the Scorpion 10SR - Engineered for those who demand uncompromising strength and reliability when the job gets tough. This powerhouse winch packs a full 10,000 lbs. of pulling capacity into a lightweight, compact design that fits where traditional winches can't, reducing stress on your vehicle without sacrificing performance. Equipped with a high-torque permanent magnet motor and instant dynamic braking, the Scorpion 10,000 features a versatile, clockable 4-stage planetary gearbox with dual-range gearing to delivering unstoppable pulling power. Safety comes standard with a full load-holding brake, integrated overload shut-off, and a 3/8" synthetic rope with soft shackle to eliminate metal-to-metal hazards. A patented drum light ensures superior visibility in low-light recoveries, while low-amp efficiency maximizes performance from a single 12V battery. Designed with convenience in mind, it also includes an ergonomic free-spool clutch and both wired and wireless remotes for ultimate control. When the terrain gets demanding, the Scorpion 10,000 is built to strike-delivering unmatched capability and confidence every time.
10SR Winch; Black;
| Brand | Superwinch |
|---|---|
| Type | Winch |
| Weight | 53 - 90 lbs |
| Brake System | 100% Full-load holding automatic mechanical brake |
| Can Ship By Ground Delivery | Yes |
| Clutch | Pull and turn clutch handle |
| Color | Graphite, Black |
| Control Box | Relocatable Die-Cast Aluminum, Internal |
| Dimensions | 22.04in L x 6.3in W x 9.67in H (559.8mm L x 160.02mm W x 245.62mm H), 16.50in L x 6.81in W x 6.75in H (Not Incl. Clutch Handle Add .92" With Handle) |
| Drilling Required | No |
| Drum | Durable fully welded steel drum |
| EN Compliant | No |
| Fairlead | Aluminum hawse, Stainless Steel 4-Way Roller |
| Finish | Powder Coated |
| Gear Ratio | 231:1, 218:1, High 156:1/Low 437:1 |
| Gear System | 3-stage planetary, 4-Stage Planetary |
| Horsepower | 5.5 |
| IP Rating | IP68 Waterproof and Dustproof |
| Line Speed | 363 Amps Motor Draw (Max Load)/4.5 FPM (1.37 MPM), 68 Amps Motor Draw/23.4 FPM (7.13 MPM), 0 lbs. - 85 Amps Motor Draw/27.3 FPM (8.32 MPM) | 10000 lbs. - 363 Amps Motor Draw/4.5 FPM (1.37 MPM), 0 lbs. - 68 Amps Motor Draw/23.4 FPM (7.13 MPM) | 12000 lbs. - 379 Amps Motor Draw/3.7 FPM (1.13 MPM) |
| Material | Steel |
| Motor | 6.0 HP, 12V DC, 5.5 HP, 12V DC, 1.9 HP, 12V DC |
| Mounting Bolt Pattern | 10in x 4.5in (254mm x 114.3mm), 10.00in x 4.50in and 6.38in x 4.50in |
| Mounting Hardware Included | Yes |
| Mounting Type | Bolt-On |
| Rated Single Line Pull (Lbs) | 10000, 12000 |
| Remote Control | Wireless hand-held remote & 12 ft handheld wired remote included (wired remote features flashlight with built-in lithium ION battery. Recharges while plugged into winch.), 12 ft Hand-held wired remote only included (wired remote features flashlight with built-in lithium ION battery. Recharges while plugged into winch.) |
| Remote Type | Wire and Wireless, Wire |
| Rope Length | 3/8 in x 80 ft (9.5mm x 24.3m), 3/8 in x 85 ft (9.5mm x 26m), 3/8 in x 54 ft (9.5mm x 16.4m) |
| Rope Material | Synthetic, Steel Wire, Synthetic, UHMWPE (Ultra-High Molecular Weight Polyethylene) Fiber |
| Task Lighting | Patented drum light, Patented drum light Patent #10,633,229 |
| Voltage | 12V DC |
| Warranty | Limited Lifetime Mechanical/7 Year Limited Electrical |
| Winch Hook | Heavy-Duty, Clevis Pinned Latched, Integrated Soft Shackle |
| Winch Model | SX12SR, SX10SR, SX10, SX12, Scorpion |
| Winch Series | SX Series, Scorpion |
| Winch Weight | 49 lbs |
7 products in this series
