16 products in this series
Trail FX offers a high quality product at an outstanding value for Light Trucks, Jeeps and Recovery vehicles. TrailFX offers you an array of products. Whether it is for work or play, TrailFX has something for everyone's needs. Step bars to grille guards
With 2 X 8 In 17600 Pound Breaking Strength Tree Trunk Protector 17600 Pound Capacity Zinc Plated Snatch Block With Grease Port Two 3/4 In 10000 Pound Rated D-Shackles Pair of Orange Gloves 10 Foot X 5/16 In 17600 Pound Rated Grade 70
| Brand | TrailFX |
|---|---|
| Type | Winch |
| Installation Time | About 15 minutes |
| Weight | 0.5 - 97 lbs |
| All Terrain Vehicle | No |
| Bag Color | Orange |
| Bag Logo | Trail FX Logo |
| Brake Activation | Electric |
| Brake Type | Automatic Full Load Brake, Drum |
| Break Strength | 9500, 3500 |
| Cable Diameter | 0.19, 0.33 |
| Cable Length | 94, 40 |
| Cable Material | Synthetic, Steel |
| Carrying Case Included | Yes |
| Choker Chain Included | Yes |
| Color | Black, Silver |
| Compatibility | Up To 12000 Pound Winch, Trail FX W35B/ WS35B/ W45B/ WS45B Winch, TrailFX XV95 Series Winches, Drape Over Winch Cable To Absorb Cable Whip, Trail FX Winches W35B/ WS35B/ W45B/ WS45B |
| Conforms To J706 Standards | No |
| Control Unit Included | No |
| Drilling Required | No |
| Drive Gear Type | 3-stage Planetary, Planetary |
| Drum Material | Steel |
| Electrical Control Type | Solenoid |
| End 1 Type | Wire Rope, Loop On |
| End 2 Type | Wire Rope, Wire Rope Terminal |
| Fairlead Type | Roller, Hawse |
| Finish | Textured Powder Coated, Matte Powder Coated |
| Free Spooling | Yes |
| Gear Ratio | 136:1 |
| Gear Reduction Ratio | 9.08, 7.50069444444445 |
| Gearing | Planetary |
| Hole Quantity | 4 |
| Includes Bag | Yes |
| Includes Bow Shackle | Yes |
| Includes Chain | Yes |
| Includes D-Shackle | Yes |
| Includes Gloves | Yes |
| Includes Mounting Hardware | Yes |
| Includes Snatch Block | Yes |
| Includes Tree Trunk Protector | Yes |
| Length | 23, 6, 28 |
| Line Diameter (in) | 0.32 Inch / 8.3mm, 0.37 Inch / 9.5mm |
| Line Length (ft) | 94 Feet |
| Line Material | Synthetic, Steel |
| Line Speed At Max Pull | 3.8 Feet Per Minute At 12000 Pound, 5.7 Feet Per Minute At 9500lb |
| Material | Steel, Synthetic, Forged Steel |
| Max Amp Draw | 400 Amp Max Draw At 9500 Pound, 405 Amp Max Draw At 12000 Pound |
| Motor Horsepower | 6.6 Horsepower, 7.0 Horsepower, 5.7 Horsepower |
| Motor Type | Series Wound Motor, Series Wound |
| Mount Type | Vehicle Mounted, Fixed Mount |
| Mounting Bolt Pattern Length | 10 |
| Mounting Bolt Pattern Width | 4.5 |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 4 |
| Mounting Pattern Length (in) | 10 Inch |
| Mounting Pattern Width (in) | 4-1/2 Inch |
| Mounting Type | Bolt-On |
| Operation Type | Automatic, Electric |
| Rated Line Pull | 9500, 12000 |
| Recommended Use | Self-recovery, Vehicle Recovery |
| Remote Included | Yes, No |
| Remote Type | Wired / Wireless, Wired |
| Roller Fairlead Included | No |
| Size | 1/4 Inch |
| Solenoid Type | Yes |
| Thermal Shutoff | No |
| Universal Or Specific Fit | Universal |
| Voltage | 12 |
| Width | 7", 5", 14" |
| Winch Rating | 9500 Pound, 12000 Pound |
| Wireless | No |
All 16 parts in this line, in part-number order.
