One of Superwinch's most popular winches, the Tiger Shark 11500 is the benchmark for performance winching while not breaking the bank. From powerful motors, to strong gears to long-life stainless steel parts, the Tiger Shark 11500 stands out from the competition. It is easy to see why the Tiger Shark remains one of Superwinch's most popular winches year after year.
Tiger Shark 11500 Winch; 11500 lbs.; 5.2hp; 12V; 3/8 in. x 84 ft. Steel Rope; Black;
| Brand | Superwinch |
|---|---|
| Type | Winch |
| Weight | 63 - 146 lbs |
| Battery Single (Recommended Capacity) | 650 CCA minimum (Dual 12V 600 CCA recommended) |
| Brake System | Mechanical, Automatic Load Holding, Automatic cone brake |
| Can Ship By Ground Delivery | Yes, No |
| Clutch | Ergonomic pull and turn, Kick-n-Flip with Safety Latch, Lever shift twist and turn freespool, Kick-n-flip |
| Color | Black |
| Dimensions | 20.8in L x 7.1in W x 4.5in H (528mm L x 180mm W x 180mm H), 24.7in L x 10.9in D x 6.2in H (624mm L x 278mm D x 157mm H), 23.7in L x 8.5in D x 9.4in H (601mm L x 216mm D x 240mm H), 24in L x 9.8in D x 7.8in H (610mm L x 249mm D x 198mm H), 24.3in L x 11.4in D x 8.5in H (618mm L x 290mm D x 216mm H), ... |
| Drum | Durable fully welded steel drum |
| Drum Diameter (in.) | 2.5, 3.5 |
| Drum Length (in.) | 9.0, 8.4 |
| Drum Size | 3.5in x 8.3in (90mm x 213mm), 3.5in x 8.8in (88mm x 223mm), 3in x 8.78in (76mm x 223mm), 5.0in x 8.2in (127mm x 209mm) |
| EN Compliant | No, Yes |
| Fairlead | 4-Way Roller, Stainless Steel 4-Way Roller, Aluminum hawse |
| Finish | Powder Coated |
| Gear Ratio | 218:1, 345:1, 262:1 |
| Gear System | 3-stage planetary |
| Line Speed | 80 Amps Motor Draw/19 FPM (5.7 MPM) |
| Material | Steel |
| Motor | Series wound 6.8 HP/5.0KW, 12V DC, Series wound 6.8 HP/5.0KW, 24V DC, Series wound 6.0 HP (4.48kW), 12V DC, Series wound 6.0 HP/4.4KW, 12V DC, Series wound 5.2 HP/3.8KW, 12V DC, ... |
| Mounting Bolt Pattern | 10in x 4.5in (254mm x 114.3mm), 10in x 4.5in (254mm x 114.3mm) + 10in x 6.7in (254mm x 172mm), 10in x 4.5in (254mm x 114mm) + 10in x 6.7in (254mm x 172mm), 10.0in x 4.5in (255mm x 114mm) + 10.0in x 6.7in (255mm x 171mm) |
| Net. Weight | 132 lbs (59.9kgs), 59 lbs (26.7kgs), 79 lbs (35.8kgs), 132 lbs (60kgs), 77 lbs (35kgs), ... |
| Rated Single Line Pull (Lbs) | 18000, 7850, 11500, 9500, 15000, ... |
| Remote Control | 12 ft Rubber Sealed Hand-held, 30 ft Hand-held remote control |
| Remote Type | Wire |
| Rope | Wire rope (10mm x 21.3m) Minimum braking strength 1960N/mm², Not Included |
| Rope Length | 33/64 in x 79 ft (13mm x 24m), 29/64 in x 85 ft (11.5mm x 26m), 3/8 in x 80 ft (9.5mm x 24.3m), 15/32 in x 78 ft (12mm x 24m), 3/8 in x 84 ft (9.5mm x 25.6m), ... |
| Rope Material | Steel Wire, Synthetic |
| Solenoid | Weather Sealed Solenoid and Circuit Breaker Protected, Weather Sealed |
| Standards Compliance | EN 14492-1. CE Directives--Machinery 2006/42/EC; Noise Emission 2000/14/EC; Electromagnetic Compatibility 2014/30/EC |
| Voltage | 12V DC, 24V DC |
| Warranty | Limited Lifetime Mechanical/3 Year Limited Electrical, Limited Lifetime Mechanical/7 Year Limited Electrical |
| Winch Hook | Heavy-Duty, Clevis Pinned Latched, 3/8in, Clevis Pin, Latched Hook, Not Included |
| Winch Model | Tiger Shark 35, Tiger Shark 18000SR, Tiger Shark 18000, Tiger Shark 15000, Tiger Shark 66.7 kN, ... |
| Winch Series | Tiger Shark Series |
15 products in this series
