4 products in this series
Built for action, the LT2000 Winch from Superwinch provides up to 2,000 lbs of reliable pulling power. This utility/multi-purpose winch features freespooling "pull and turn" clutch and a Handle bar mounted rocker switch remote, perfect for a variety of uses. Perfected over the years, the LT Series offer unmatched durability and performance.
LT2000 Winch; 2000 lbs.; 1.0hp; 12V; 5/32 in. x 49 ft. Steel Rope; Black;
| Brand | Superwinch |
|---|---|
| Type | Winch |
| Weight | 18 - 29 lbs |
| Brake System | Automatic, 100% Load Holding |
| Can Ship By Ground Delivery | Yes |
| Clutch | Free Spooling, Ergonomic Control, Free-Spooling, Pull and Turn |
| Color | Black |
| Dimensions | 13.2 L x 4.25 W x 4.25 H (335.3mm L x 108mm W x 108mm H), 11.0in L x 4.1in D x 4.1in H (285mm L x 105mm D x 105mm H) |
| Drum Diameter (in.) | 2, 1.25, 2.0 |
| Drum Length (in.) | 2.9, 2.83 |
| EN Compliant | No |
| Fairlead | 4-Way Roller, Aluminum hawse |
| Finish | Powder Coated |
| Gear Ratio | 153:1, 166:1 |
| Gear System | 3-stage planetary, 1-stage planetary |
| Line Speed | 20 Amps Motor Draw/18 FPM (5.4 MPM), 15 Amps Motor Draw/27 FPM (8.3 MPM), 10 Amps Motor Draw/10.0 FPM (3.0 MPM) |
| Material | Steel |
| Motor | 1.4 HP, sealed permanent magnet motor, 12V DC, 1.0 HP, sealed permanent magnet motor, 1.2 HP, sealed permanent magnet motor |
| Mounting Bolt Pattern | 3.0in x 4.87in (76mm x 124mm), 2 Hole, 3.15in (80mm) on Center |
| Net. Weight | 25 lbs (11.3kgs), 14.2 lbs (6.4kgs), 20 lbs (9.0kgs) |
| Rated Single Line Pull (Lbs) | 4000, 2000, 3000 |
| Remote Control | 12 ft Rubber Sealed Hand-held plus Handle Bar Rocker Switch, 12 ft Rubber Sealed Hand-held, 8 ft Handle Bar Mounted Rocker Switch |
| Remote Type | Wire |
| Rope Length | 3/16 in x 50 ft (4.8mm x 15.2m), 5/32 in x 50 ft (3.9mm x 15.2m) |
| Rope Material | Steel Wire, Synthetic |
| Solenoid | Sealed Solenoid; Circuit Breaker Protected, Sealed, circuit breaker protected |
| Voltage | 12V DC |
| Warranty | 1 Year Limited Manufacturer |
| Winch Hook | Heavy-Duty, Clevis Pinned Latched |
| Winch Model | LT4000SR, LT2000, LT4000, LT3000 |
| Winch Series | LT Series |
All 4 parts in this line, in part-number order.
