Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.
Application specific valving to maximize performance
| Brand | FOX Offroad Shocks |
|---|---|
| Type | External Bypass Shock |
| Weight | 18 - 46 lbs |
| Adjuster Type | External Bypass Clicker - Gen 2, DSC - Dual Speed Compression |
| Body Diameter (in) | 2.5 |
| Body Finish | FOX Grey Cerakote |
| Body Material | Steel, Aluminum |
| Bottom Mount | Eyelet |
| Bypass Tubes | 4, 3 |
| Compressed Length (in) | 18.55, 27.55, 23.55, 25.55, 16.55, ... |
| Extended Length (in) | 37.50, 45.50, 41.50, 28.50, 32.50, ... |
| Eyelet Length (in) | 2.00 |
| Fox Catalog | OFFROAD, TRUCK |
| Hose | -10 x 38.00, -10 x 28.00 |
| Label Name | 2.5 FRS, EXBP, 4T, P/B, 10", LH, 2.5 FRS, EXBP, 4T, P/B, 18", LH, 2.5 FRS, EXBP, 4T, R/R, 14", LH, 2.5 FRS, EXBP, 3T, P/B, 10", LH, Kit: 03-24 Toyota 4Runner, 07-14 FJ Cruiser, Rear, 2.5 Truck FRS IBP, R/R, 0-1.5" Lift, DSC, ... |
| Mounting | 1/2 x 1-1/2 |
| Reservoir Dimensions | 2.55 x 14.00, 2.55 x 10.00, 2.55 x 8.00 |
| Reservoir Type | Remote, Piggyback |
| Series | Factory Race |
| Shaft Size (in) | 7/8 |
| Top Mount | Eyelet, Stem |
| Travel (in) | 7.95, 13.95, 17.95, 11.95, 15.95, ... |
| Valving | 807-24-494 |
Use the Find Your Fit tool above to check if this product fits your specific vehicle.
