6 products in this series
The real magic happens when paired with a WorkLink™ harness. These harnesses allow you to hook up 2-4 lights to a pre-built wiring system that supports up to 320W (depending on the setup you choose). WorkLink™ harnesses include a switch, power connection, fuse, and extension harnesses.
BUILTBRIGHT Work Pod Task LED work light, White, 6000K, weatherproof IP69K rated, aluminum housing with stainless hardware. Compatible with 12V and 24V DC systems. (1 EA)
| Brand | ARC Lighting |
|---|---|
| Type | Work Light |
| Installation Time | About 1 hour 15 minutes |
| Weight | 1 - 3 lbs |
| Add-On | 84002/BB84041/BB84043, BB84042/BB84044, BB84042 |
| Amp Draw per Bulb | 5.5A @ 12V DC, 3A, 4A @ 12V DC, 3A @ 12V DC |
| Beam Pattern | Flood |
| Cable Length | 11.0 in. |
| Color | White, White, Amber, Warm White |
| Color Temp. (CCT) | 6000K |
| Color Temperature | 6,500K, 6000K (White), 1700K (Amber), 4000K (Warm White), 6,000K, 6,500K (White), 1,700K (Amber), 4,000K (Warm White) |
| Connector | Pigtail |
| Current Draw | 2A @ 12V DC |
| Dimension | 3.88" H x 2.77" W x 1.74" D, 4" H x 4" W x 2.5" D, 4" H x 4" W x 1" D |
| Dimensions | 1.25” H x 6.5" W x 1.3" D |
| EMC Compliance | CISPR 25 Class 3 |
| Hardware Material | 304 Stainless Steel |
| Housing Material | Powder-Coated Cast Aluminum |
| IP Rating | IP69K |
| LED Color | White |
| LED Count | 6 |
| Lens Color | Clear |
| Lens Material | High-Strength, UV-Stabilized Polycarbonate |
| Light Output | 4,800 LM, 8,000 LM, 3,600 LM, 6,800 LM (White), 1,300 LM (Amber), 8,000 LM (Warm White), 2,650 LM (White); 1,300 LM (Amber); 3,300 LM (Warm White) |
| Lumen Output | 1700LM |
| Operating Temperature | -40°F to +185°F |
| Operating Voltage | 10-36V DC |
| Power | 20W |
| Power Consumption | 30W, 80W, 60W |
| Terminal Type | DT Male/Female Pigtails |
| Voltage | 10-48V DC |
| Warranty | 5-Year Warranty |
| Weatherproof Rating | IP69K |
| Wire Length | 11" |
All 6 parts in this line, in part-number order.
