Bilstein P/N 25-343854

B8 5100, Type III Hard Anodized

Description

Bilstein M 9400 (Coilover) Black Hawk shock absorbers are built to dominate off-road terrain with race-proven performance and precision tuning. Featuring 4-way adjustability and multiple stroke lengths, these universal coilovers adapt to a wide range of UTV and off-road setups. At the core is Bilstein’s patented ZoneControl technology—five independently tuned damping zones (3 compression, 2 rebound) with an internal Jounce Cut Off (JCO) and Rebound Cut Off (RCO) for bottom-out and droop control—no limit straps needed. The JCO acts as a two-stage hydraulic bump stop and includes a 10 position adjustment for fine tuning the bottom out control. The RCO engages in the final stage of droop to give more control and protect the damper. 9400 Black Hawk Powersports dampers provide 4 unique external adjustments that are easily accessible; high/low speed compression, rebound and JCO. Crafted from lightweight aluminum with gold-finned reservoirs, these coilovers are fully serviceable and track-ready out of the box. Springs and coilover hardware sold separately for custom comfort and performance. Upgrade your offroad or UTV experience with Bilstein’s unique “bottomless” ride on the 9400 Black Hawk Powersports universal coilover dampers

70mm Monotube Shock Absorber

Specifications

BrandBilstein
Part Number25-343854
Body DesignThreaded Body (Coilover)
Body MaterialAluminum alloy
Collapsed Length (IN)24.50
Collapsed Length (mm)622.2
Extended Length (IN)38.50
Extended Length (mm)978.0
FinishType III Hard Anodized
Heim Spacer KitB4-KT1-Z241A07
Internal DesignMonotube
Lower Mount TypeEye 5/8in
Mount TypeEye-to-Eye
PartTypeShocks / Struts
Piston Diameter70mm
ReservoirYes
SegmentMotorsports
SeriesM 9400 Black Hawk
Shaft Diameter (mm)25.4
Spring Hardware13-360054
Upper Mount TypeEye 5/8in
Additional ComponentsRequires use of coilspring hardware kit 13-360054
Adjustable Damping4-Way Adjustable - High and Low Speed Compression, Rebound, JCO-Jounce Cut-Off (Hydraulic Bump)
Weight32.7 lbs

Vehicle Fitment

No fitment data available.

Bilstein P/N 25-343854

B8 5100, Type III Hard Anodized

$1,578.00

Check if this fits your vehicle Select your vehicle
Professional installation available
We install this! Suspension, wheel and tire labor varies a lot by vehicle and setup - contact your local store for an exact installation quote.
Built to orderShips direct from the manufacturer to your local H&H store. Call 888-865-4024 for lead times.
