Bolt-On Lift Kit w/Shocks; 3 in. Lift; Incl. Front Upper Control Arms; Strut Spacers; SwayBar Links; Lift Blocks; U-Bolts; Premium N3 Shocks;
Rough Countrys 3in Bolt-On Kit offers easy installation and aggressive good looks at an incredible value. Take your truck to new heights with this excellent option for standard Nissan Titan pickups.This kit features a set of high-quality, tubular Upper Control Arms designed to make alignment adjustments easier and Clevite rubber bushings for enhanced durability. These arms are designed to promote a factory-like geometry by keeping the ball joint at optimum angles after lifting. This design allows for an improved, greater range of motion from the ball-joint, with less stress, wear and tear.Also included are a set of durable strut spacers and fabricated rear blocks to provide lift height from front to rear. Once installed, this kit gives your truck plenty of ride height for up to 33in tires while offering a clean, level look from front to rear.This all-inclusive kit comes with everything you need, and installation is a piece of cake compared to other kits on the market! Featuring a 100% bolt-on installation process that requires zero cutting or drilling, this kit can be installed using common tools in a home garage, and allows the truck to be returned to stock at any time if so desired. Best of all this kit features Rough Countrys Lifetime Replacement Warranty.
- 10-Stage Variable Valving
- For Enhanced Durability
- Strut Spacer Kit Requires No Strut Disassembly Or
- Strut Compressor For Installation [83400]
- Lifetime Replacement Warranty*
- High Pressure Nitrogen Charged
- Increased Ground Clearance
- Levels The Front And Rear Of The Truck
- Incl. New Tubular Upper Control Arms
- Control Arms Keep Ball Joints At Optimum Angles
- For Less Wear And Tear
- Control Arms Incl. Clevite Rubber Bushings
Information:
FRONT: (2) Upper control arms, (2) Strut spacers, (2) Sway-bar links, Hardware; REAR: (2) Lift Blocks, (4) U-bolts, Hardware
Application Summary:
| Year |
Make/Model |
| 2004-2015 |
Nissan TITAN |
| 2017-2024 |
Nissan TITAN |
| 2016 |
Nissan TITAN XD |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
CN |
| Front Components |
(2) Upper control arms, (2) Strut spacers, (2) Sway-bar links, Hardware |
| Front Kit Componenets |
(2) Upper control arms, (2) Strut spacers, (2) Sway-bar links, Hardware |
| Front Kit Components |
(2) Upper control arms, (2) Strut spacers, (2) Sway-bar links, Hardware |
| GTIN |
00843030149697 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
4-6 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
3 in. |
| NAFTA Preference Criterion Code |
B |
| Rear Components |
(2) Lift Blocks, (4) U-bolts, Hardware |
| Rear Kit Components |
(2) Lift Blocks, (4) U-Bolts, Hardware |
| SDR Required Flag |
N |
| Tire & Wheel Size Combinations |
33x12.50 R22 - Factory 22x9in wheel, 33x12.50 R22 - Factory 22x9in wheel |
| Tire, Wheel, and Offset Info |
33x12.50R22:Factory 22:6x5.5:-:-; 33x12.50R20:Factory 20:6x5.5:-:-; 33x12.50R18:Factory 18:6x5.5:-:-; 33x12.50R17:Factory 17:6x5.5:-:-; 285 70R17:17x8.5:6x5.5:+0:-; 285 70R17:17x8.5:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+0:-; 285 70R17:17x9:6x5.5:+1:-; 285 70R17:17x9:6x5.5:+18:-; 285 70R17:17x9:6x5.5:+20:-; 285 65R18:18x8.5:6x5.5:+0:-; 285 65R18:18x8.5:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+0:-; 265 65R18:18x9:6x5.5:+0:-; 285 65R18:18x9:6x5.5:+1:-; 265 65R18:18x9:6x5.5:+1:-; 285 65R18:18x9:6x5.5:+18:-; 265 65R18:18x9:6x5.5:+18:-; 285 65R18:18x9:6x5.5:+19:-; 265 65R18:18x9:6x5.5:+19:-; 285 65R18:18x9:6x5.5:+20:-; 265 65R18:18x9:6x5.5:+20:-; 285 55R20:20x9:6x5.5:+0:-; 285 55R20:20x9:6x5.5:+1:-; 285 55R20:20x9:6x5.5:+18:-; 285 55R20:20x9:6x5.5:+20:- |
