Suspension Lift Kit; 6 in. Lift; Diesel;
This suspension features luxury ride coil springs matching OE coils rates that are specifically designed for gas or diesel motors. A heavy duty track bar relocation bracket properly centers the axle and matches the steering angles created by the supplied drop pitman arm while the radius arm drop brackets maintain the Super Dutys O.E. caster angles. A steering stabilizer relocation bracket maintains proper steering control but a RC problem solver single unit is recommended with larger tires and a RC dual stabilizer is required when running 37in tires.
This suspension features luxury ride coil springs matching OE coils rates that are specifically designed for gas or diesel motors. A heavy duty track bar relocation bracket properly centers the axle and matches the steering angles created by the supplied drop pitman arm while the radius arm drop brackets maintain the Super Dutys O.E. caster angles. A steering stabilizer relocation bracket maintains proper steering control but a RC problem solver single unit is recommended with larger tires and a RC dual stabilizer is required when running 37in tires.
- Easy Bolt-On Installation
- Increased Ground Clearance
- Levels The Front w/The Rear Of The Vehicle
- No Need To Disassemble Your Struts To Install
Information:
Does NOT fit gas engine models. Does NOT fit dually models. If vehicle is equipped with rear overload leafs, they will need to be removed.Application Summary:
| Year | Make/Model |
|---|---|
| 2005-2007 | Ford F-250 Super Duty |
| Attributes | |
| California Proposition 65 | No |
| Country of Origin (Primary) | TH |
| Front Components | Lifted coil springs, Radius arm drop brackets, Sway-bar link extensions, Track bar drop bracket, Stabilizer relocation brackets, Pitman arm, Brake line brackets, Bumpstop spacers, Hardware |
| Front Kit Components | Lifted coil springs, Radius arm drop brackets, Sway-bar link extensions, Track bar drop bracket, Stabilizer relocation brackets, Pitman arm, Brake line brackets, Bumpstop spacers, Hardware |
| GTIN | 00843030152994 |
| Harmonized Tariff Code (Schedule B) | 8708809900 |
| Hazardous Material Code | N |
| Install Time | 6-8 hours |
| Life Cycle Status Code | Available to Order |
| Lift/Drop Height | 6 in. |
| NAFTA Preference Criterion Code | D |
| Rear Components | 3in lift blocks, Add-a-leafs, Carrier bearing drop bracket, U-bolts, Hardware |
| Rear Kit Components | 3in lift blocks, Add-a-leafs, Carrier bearing drop bracket, U-bolts, Hardware |
| SDR Required Flag | N |
| Tire, Wheel, and Offset Info | 37x13.50R17:17x9:8x170:-12:-; 37x13.50R17:17x9:8x170:+0:-; 37x13.50R17:17x9:8x170:+1:-; 37x13.50R18:18x9:8x170:-12:-; 37x13.50R18:18x9:8x170:+0:-; 37x13.50R18:18x9:8x170:+1:-; 37x13.50R20:20x9:8x170:-12:-; 37x13.50R20:20x9:8x170:+0:-; 37x13.50R20:20x9:8x170:+1:-; 37x12.50R20:20x10:8x170:-25:-; 37x12.50R20:20x10:8x170:-24:-; 37x12.50R20:20x10:8x170:-19:-; 35x12.50R20:20x10:8x170:-19:-; 37x12.50R20:20x10:8x170:-18:-; 35x12.50R20:20x10:8x170:-18:-; 37x12.50R20:20x12:8x170:-44:Trimming Required; 35x12.50R20:20x12:8x170:-44:Trimming Required; 37x12.50R22:22x10:8x170:-25:-; 37x12.50R22:22x10:8x170:-24:-; 37x12.50R22:22x10:8x170:-19:-; 35x12.50R22:22x10:8x170:-19:-; 37x12.50R22:22x10:8x170:-18:-; 35x12.50R22:22x12:8x170:-44:Trimming Required |
Rough Country 59350 6in Ford Suspension Lift Kit (Diesel)
Product Information
- Brand: Rough Country
- Product Number: 59350
- Availability: 1 in stock at Main Warehouse
*Allow 2-3 business days to ship to your local H&H store. (In stock items only)
$2,599.95
Install with Alignment +$930.00
