6.5in ECO-LIGHT LED Light Bars w/ 3D Reflector Optics & High Performance Diodes
Race Sport Lighting's ECO-Light series LED light bars feature proprietary optics for unmatched light output, all at an economical price point making them our premier entry level LED bar. - 36W - 2.8 AMPs - 2,340 Lumens - Combination light pattern - 9-16v Voltage Range - Bar Height: 3 (75.75mm) - Mounted Height (Level to Mounting Surface): 4 (101.875mm) - 8 Bar Length End-to-End - 11 Bar Length including Mount - 1 Year Warranty
- 6.5 ECO-LIGHT LED Light Bars w/ 3D Reflector Opticals
- Current Draw: 2.8A
- Wattage: 36-Watts
- Chip Type: Phillips
- IP67 rating
- Kelvin (Color Temperature): 6,500K
- Beam Pattern: Combo
- Lumens: 2,340lm
- Bar Height: 3 (75.75mm)
- Mounted Height (Level to Mounting Surface): 4 (101.875mm)
- 8 Bar Length End-to-End
- 11 Bar Length including Mount
- 1 Year Warranty
- Life Expectancy: 50,000 hours
- Operating Voltage: 9-16VDC
Information:
Race Sport Lighting's ECO-Light series LED light bars feature proprietary optics for unmatched light output, all at an economical price point making them our premier entry level LED bar.? 36W? 2.8 AMPs? 2,340 Lumens? Combination light pattern? 9-16v Voltage Range? Bar Height: 3 (75.75mm)? Mounted Height (Level to Mounting Surface): 4 (101.875mm)? 8 Bar Length End-to-End? 11 Bar Length including Mount? 1 Year Warranty
Application Summary:
| Year |
Make/Model |
| LED |
Light Bar |
| Attributes |
| AAP Selling Package Quantity |
1 |
| AAP Selling Package Quantity UOM |
EA |
| AAP_UDA_12 |
EA |
| AAP_UDA_22 |
1 |
| AAP_UDA_4 |
65 |
| Add-On |
N/A |
| Alternate Part Number |
RS36 |
| ASIN |
B016QW7C1U |
| Attribute Data |
RS36 |
| Battery Location Info |
N/A |
| Beam Pattern |
Combo |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Chip Type |
PHILLIPS |
| Contain Battery |
No |
| Country of Origin (Primary) |
CN |
| Cross-Sell Skus |
RS3X3ECO,RS3X3FECO |
| Current Draw |
2.8A |
| Estimated Install Time |
1 Hour |
| Exportable |
Yes |
| Freight Class |
65 |
| Harmonized Tariff Code (Schedule B) |
8512202080 |
| Hazardous Material Code |
N |
| HAZMAT Item |
No |
| IP Rating |
IP67 |
| Kelvin (Color Temperature) |
6,500K |
| Lead Time AVG |
1 Day |
| Life Cycle Status Code |
Available to Order |
| Life Expectancy |
50,000 hours |
| Lumens |
2,340lm |
| NAFTA Preference Criterion Code |
B |
| Operating Voltage |
9-16VDC |
| Related Skus |
RSTP016,RS-HARN-SS2 |
| Returnable |
Yes |
| Reverse Polarity Protection |
Yes |
| SDR Required Flag |
N |
| SEMA Product Type |
Light Bar |
| Shipping Port |
Chicago |
| Territory Restrictions |
No |
| Upsell Skus |
RS-LED-36W |
| Warranty |
3 year |
| Warranty Process |
https://www.racesportinc.com/rma |
| Warranty Time |
3 |
| Wattage |
36-Watts |
| GTIN |
00814843021791 |
