Magnaflow Off Road Pro Series Gas Stainless Cat-Back
The MagnaFlow 2000-2006 Jeep Wrangler Off-Road Pro Series Cat-Back Performance Exhaust System brings additional off-roading prowess and our deep signature exhaust note to your 2.4L, 2.5L, 4.0L 2000-2006 Jeep Wrangler with a weight-optimized, dyno-tested, corrosion resistant and durable stainless steel design engineered to closely hug the undercarriage for improved ground clearance. Exhaust kit 17122 is engineered to produce Very Aggressive exterior and Aggressive interior sound levels. Extensive 3D scanning was used during the development of this Jeep Wrangler exhaust system to create a direct-fit design, enabling a do-it-yourself installation process. 17122's emissions-legal cat-back design replaces all your truck's exhaust components from the catalytic converter on back with its 2.5in. diameter mandrel bent main piping that passes through 1 Straight-Through mufflers before ending in a turndown before rear axle exit with 3in. Satin Clamp-On Single Wall Turndown Cut Edge tips. Exhaust system 17122 is produced using advanced CNC precision robotic manufacturing techniques and backed by MagnaFlow's limited lifetime warranty.
- 100% Stainless Steel
- High flow straight through design
- Available for gas or diesel trucks and SUV's
Information:
Need further assistance? Call 1-800-990-0905.
Application Summary:
| Year |
Make/Model |
| 2000-2006 |
Jeep Wrangler |
| Attributes |
| Anticipated Ship Out Time |
Approximately 1-2 Days |
| ASIN |
B004SCQTSS |
| Attachment Style |
Bolt-On |
| Attachment Type |
Bolt-On |
| California Proposition 65 |
No |
| Catalytic Converter Included |
No |
| Clamping Type |
Round Band |
| Clamps Included |
Yes |
| Color/Finish |
Stainless |
| Components |
Band Clamp=1 |
| Country of Origin (Primary) |
US |
| Exhaust Inlet Connection Type |
Bolt-On |
| Exhaust Pipe Material |
Stainless |
| Exhaust Tip Diameter |
3 |
| Exhaust Tip Finish |
Satin |
| Exhaust Tip Material |
Stainless Steel |
| Exhaust Tip Quantity |
1 |
| Exhaust Type |
Single |
| Exit Location |
Turn Down In Front of Rear Tire |
| Exit Position |
Turn Down In Front of Rear Tire |
| Exit Quantity |
Single |
| Exit Style |
Turndown In Front Of Rear Tire |
| Finish |
Stainless, Stainless Steel |
| Gasket Or Seal Included |
No |
| Hangers Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Connection Type |
Bolt-On |
| Inlet Inside Diameter |
2.500 in. |
| Inlet Inside Diameter (in.) |
2.5 |
| Inlet Size (in.) |
2.5 |
| Inlet Type |
Bolt-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2.500 in. |
| Main Piping Diameter (in.) |
2.5 |
| Material |
Stainless |
| Mounting Bracket Included |
No |
| Muffler Body Diameter |
5.000 in. x 5.000 in. |
| Muffler Body Diameter (in.) |
5 x 5 |
| Muffler Body Finish |
Satin |
| Muffler Body Height |
5.000 in. |
| Muffler Body Height (in.) |
5.000 in. |
| Muffler Body Length |
14.000 in., 14 |
| Muffler Body Length (in.) |
14 |
| Muffler Body Material |
Stainless Steel, Stainless Steel |
| Muffler Body Shape |
Round |
| Muffler Body Width |
5.000 in. |
| Muffler Body Width (in.) |
5.000 |
| Muffler Count |
1 |
| Muffler Finish |
Satin |
| Muffler Material |
Stainless Steel |
| Muffler Quantity |
1, 1 |
| Muffler Type |
Straight-Through, Straight-Through |
| NAFTA Preference Criterion Code |
B |
| Outlet Outside Diameter |
3.000 in. |
| Outlet Outside Diameter (in.) |
3 |
| Outlet Size (in.) |
3 |
| Oversize Shipping |
841380056092 |
| Pipe Material |
Stainless Steel, Stainless Steel |
| Recommended Use |
Performance |
| SDR Required Flag |
N |
| Series |
Off Road Pro, Off Road Pro |
| Sound Level |
Aggressive |
| Subtitle |
Cat-Back |
| Subtitles |
Cat-Back |
| System Type |
Cat Back |
| Tail Pipe Diameter |
2.500 in. |
| Tip Diameter |
3.000 in. |
| Tip Diameter (in.) |
3 |
| Tip Finish |
Satin |
| Tip Length |
10.000 in. |
| Tip Length (in.) |
10 |
| Tip Material |
Stainless Steel |
| Tip Quantity |
1 |
| Tip Shape |
Round |
| Tip Size |
3 in. |
| Tip Type |
Clamp-On;Single Wall;Turndown;Cut Edge |
| Tubing Diameter |
2.500 in. |
| Type |
Cat-Back, Cat-Back |
| Valve Included |
No |
| Warranty |
Lifetime |
| Warranty Time |
12 |
| GTIN |
00841380056092 |
