Magnaflow Touring Series Stainless Cat-Back System
The MagnaFlow 2008-2010 BMW 535i Touring Series Cat-Back Performance Exhaust System is the perfect partner for your 3.0L 2008-2010 BMW 535i to take on a grand tour or a weekend cruise thanks to the powerful, resonant exhaust note and dyno-proven performance it brings to the table. This durable, corrosion resistant stainless steel exhaust kit is engineered to conquer the miles with ease while enhancing your driving experience with Moderate exterior and Mild interior sound levels generated through its fast-flowing, mandrel bent 2.5in. main piping and 2 Straight-Through muffler that terminate in a Dual Straight Driver Side Rear exit with 3.5in. Polished Welded-On Double Wall Angle Cut Folded Edge tips. 16553 features a cat-back layout design to replace your import's stock exhaust components from the catalytic converter on back. This BMW 535i exhaust system is compatible with 2008-2010 engines. The use of extensive 3D scans made during the development process has resulted in an easy-to-install, direct-fit design that fits your BMW 535i like a glove. 16553 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's limited lifetime construction warranty.
- Mandrel bent tubing
- Increased Horsepower and Torque
- 409 Stainless Steel Construction
Information:
Need further assistance? Call 1-800-990-0905.
Application Summary:
| Year |
Make/Model |
| 2008-2010 |
BMW 535i |
| Attributes |
| Anticipated Ship Out Time |
Approximately 1-2 Days |
| ASIN |
B0031I5T18 |
| Attachment Style |
Clamp-On |
| Attachment Type |
Clamp-On |
| California Proposition 65 |
No |
| Catalytic Converter Included |
No |
| Clamping Type |
Round Band |
| Clamps Included |
Yes |
| Color/Finish |
Stainless |
| Components |
Band Clamp=4 |
| Country of Origin (Primary) |
US |
| Exhaust Inlet Connection Type |
Clamp-On |
| Exhaust Pipe Material |
Stainless |
| Exhaust Tip Diameter |
3.5 |
| Exhaust Tip Finish |
Polished |
| Exhaust Tip Material |
Stainless Steel |
| Exhaust Tip Quantity |
2 |
| Exhaust Type |
Dual |
| Exit Location |
Dual Straight Driver Side Rear |
| Exit Position |
Dual Straight Driver Side Rear |
| Exit Quantity |
Dual |
| Exit Style |
Dual Straight Driver Side Rear |
| Finish |
Stainless, Stainless Steel |
| Gasket Or Seal Included |
No |
| Hangers Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Connection Type |
Clamp-On |
| Inlet Inside Diameter |
2.500 in. |
| Inlet Inside Diameter (in.) |
2.5 |
| Inlet Size (in.) |
2.5 |
| Inlet Type |
Clamp-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2.500 in. |
| Main Piping Diameter (in.) |
2.5 |
| Material |
Stainless |
| Mounting Bracket Included |
No |
| Muffler Body Diameter |
4.000 in. x 9.000 in. |
| Muffler Body Diameter (in.) |
4 x 9 |
| Muffler Body Finish |
Polished |
| Muffler Body Height |
4.000 in. |
| Muffler Body Height (in.) |
4.000 in. |
| Muffler Body Height Position Front |
4 |
| Muffler Body Height Position Rear |
5 |
| Muffler Body Length |
14.000 in. |
| Muffler Body Length (in.) |
14 |
| Muffler Body Length Position Front |
14 |
| Muffler Body Length Position Rear |
18 |
| Muffler Body Material |
Stainless Steel, Stainless Steel |
| Muffler Body Shape |
Oval |
| Muffler Body Width |
9.000 in. |
| Muffler Body Width (in.) |
9.000 |
| Muffler Body Width Position Front |
9 |
| Muffler Body Width Position Rear |
8 |
| Muffler Count |
2 |
| Muffler Finish |
Polished |
| Muffler Material |
Stainless Steel |
| Muffler Quantity |
2, 2 |
| Muffler Type |
Straight-Through, Straight-Through |
| NAFTA Preference Criterion Code |
B |
| Outlet Outside Diameter |
3.500 in. |
| Outlet Outside Diameter (in.) |
3.5 |
| Outlet Size (in.) |
3.5 |
| Oversize Shipping |
841380051745 |
| Pipe Material |
Stainless Steel, Stainless Steel |
| Recommended Use |
Performance |
| SDR Required Flag |
N |
| Series |
Touring, Touring |
| Sound Level |
Moderate |
| Subtitle |
Cat-Back |
| Subtitles |
Cat-Back |
| System Type |
Cat Back |
| Tail Pipe Diameter |
2.500 in. |
| Tip Diameter |
3.500 in. |
| Tip Diameter (in.) |
3.5 |
| Tip Finish |
Polished |
| Tip Length |
5.500 in. |
| Tip Length (in.) |
5.5 |
| Tip Material |
Stainless Steel |
| Tip Quantity |
2 |
| Tip Shape |
Round |
| Tip Size |
3.5 in. |
| Tip Type |
Welded;Double Wall;Angle Cut;Folded Edge |
| Tubing Diameter |
2.500 in. |
| Type |
Cat-Back, Cat-Back |
| Valve Included |
No |
| Warranty |
Lifetime |
| Warranty Time |
12 |
| GTIN |
00841380051745 |
