Magnaflow Street Series Stainless Crossmember-Back System
The MagnaFlow 1967-1970 Ford Mustang Street Series Crossmember-Back Performance Exhaust System 15816 brings enhanced engine sound and dyno-proven performance to your 3.3L, 4.1L, 4.7L, 5.0L, 5.8L, 6.4L, 7.0L 1967-1970 Ford Mustang with a healthy helping of our deep, resonant signature exhaust note at Moderate exterior and Mild interior sound levels. Thanks to its durable, corrosion resistant stainless steel design, this Ford Mustang exhaust system will handle whatever tarmac you decide to leave your mark on. This performance exhaust kit features a crossmember-back layout designed to replace your Ford Mustang's exhaust system from the crossmember on back. With its fast-flowing, mandrel bent 2.5in. main piping and 2 Straight-Through mufflers ending in a Dual Split Rear exit with 2.75in. Polished Welded-On Single Wall Turndown Cut Edge tips, your muscle car will be sounding as awesome as it looks. Extensive 3D scanning during development has resulted in a direct-fit design that you can easily install yourself. 15816 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's limited lifetime construction warranty.
- Durable corrosion-resistant stainless steel construction
- CNC precision robotic manufacturing techniques
- Dyno-proven performance
Information:
Need further assistance? Call 1-800-990-0905.
Application Summary:
| Year |
Make/Model |
| 1967-1970 |
Ford Mustang |
| Attributes |
| ASIN |
B000COTEUQ |
| Anticipated Ship Out Time |
Approximately 1-2 Days |
| Attachment Style |
Weld-On |
| Attachment Type |
Weld-On |
| California Proposition 65 |
No |
| Clamping Type |
Band Clamp |
| Clamps Included |
Yes |
| Color/Finish |
Stainless |
| Components |
Band Clamp=8;Bolt=6;Bracket=4;Grommet=2;Isolator=2;Nut=4;Screw=4;Washer=4 |
| Country of Origin (Primary) |
US |
| Exhaust Inlet Connection Type |
Weld-On |
| Exhaust Pipe Material |
Stainless |
| Exhaust Tip Diameter |
2.75 |
| Exhaust Tip Finish |
Polished |
| Exhaust Tip Material |
Stainless Steel |
| Exhaust Tip Quantity |
2 |
| Exhaust Type |
Dual |
| Exit Location |
Dual Split Rear |
| Exit Position |
Dual Split Rear |
| Exit Quantity |
Dual |
| Exit Style |
Dual Split Rear |
| Finish |
Stainless, Stainless Steel |
| GTIN |
00841380013514 |
| Gasket Or Seal Included |
No |
| Hangers Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Connection Type |
Weld-On |
| Inlet Inside Diameter |
2.500 in. |
| Inlet Inside Diameter (in.) |
2.5 |
| Inlet Size (in.) |
2.5 |
| Inlet Type |
Weld-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2.500 in. |
| Main Piping Diameter (in.) |
2.5 |
| Material |
Stainless |
| Mounting Bracket Included |
No |
| Muffler Body Diameter |
4.000 in. x 9.000 in. |
| Muffler Body Diameter (in.) |
4 x 9 |
| Muffler Body Finish |
Polished |
| Muffler Body Height |
4.000 in. |
| Muffler Body Height (in.) |
4.000 in. |
| Muffler Body Length |
14.000 in., 14 |
| Muffler Body Length (in.) |
14 |
| Muffler Body Material |
Stainless Steel, Stainless Steel |
| Muffler Body Shape |
Oval |
| Muffler Body Width |
9.000 in. |
| Muffler Body Width (in.) |
9.000 |
| Muffler Count |
2 |
| Muffler Finish |
Polished |
| Muffler Material |
Stainless Steel |
| Muffler Quantity |
2, 2 |
| Muffler Type |
Straight-Through, Straight-Through |
| NAFTA Preference Criterion Code |
B |
| Outlet Outside Diameter |
2.750 in. |
| Outlet Outside Diameter (in.) |
2.75 |
| Outlet Size (in.) |
2.75 |
| Oversize Shipping |
841380013514 |
| Pipe Material |
Stainless Steel, Stainless Steel |
| Recommended Use |
Performance |
| SDR Required Flag |
N |
| Series |
Street, Street |
| Sound Level |
Moderate |
| Subtitle |
Crossmember-Back |
| Subtitles |
Crossmember-Back |
| System Type |
Crossmember Back |
| Tail Pipe Diameter |
2.500 in. |
| Tip Diameter |
2.750 in. |
| Tip Diameter (in.) |
2.75 |
| Tip Finish |
Polished |
| Tip Length |
9.000 in. |
| Tip Length (in.) |
9 |
| Tip Material |
Stainless Steel |
| Tip Quantity |
2 |
| Tip Shape |
Round |
| Tip Size |
2.75 in. |
| Tip Type |
Welded;Single Wall;Turndown;Cut Edge |
| Tubing Diameter |
2.500 in. |
| Type |
Crossmember-Back, Crossmember-Back |
| Valve Included |
No |
| Warranty |
Lifetime |
| Warranty Time |
12 |
