Magnaflow Street Series Stainless Cat-Back System
The MagnaFlow Street Series Cat-Back Performance Exhaust System 15693 brings out the personality of your Car with our signature resonant, powerful engine tone and dyno-proven performance. Thanks to its fast-flowing, mandrel bent 2.5in. main piping and 1 Straight-Through mufflers ending in a Dual Split Rear exit with 3.5in. Polished Welded-On Single Wall Angle Cut Edge tips, this Car exhaust kit has the performance chops to match its sporty sound and appearance. Upgrade your ride to the next level with an exhaust that has the pipes to put other Car's to shame. With this system your vehicle will be producing Moderate exterior and Mild interior sound levels while leaving other cars and trucks feeling envious at every stoplight. Exhaust kit 15693 features a cat-back layout that replaces your ride's stock exhaust components from near the catalytic converter on back. Extensive 3D scanning during development has resulted in a direct-fit design that you can easily install yourself. 15693 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's 1-year limited finish warranty and limited lifetime construction warranty.
- Dyno-proven performance
- CNC precision robotic manufacturing techniques
- Durable corrosion-resistant stainless steel construction
Information:
Need further assistance? Call 1-800-990-0905.
Application Summary:
| Year |
Make/Model |
| 1998-2002 |
Chevrolet Camaro |
| 1998-2002 |
Pontiac Firebird |
| Attributes |
| Anticipated Ship Out Time |
Approximately 1-2 Days |
| ASIN |
B000CC9CH8 |
| Attachment Style |
Bolt-On |
| Attachment Type |
Bolt-On |
| California Proposition 65 |
No |
| Catalytic Converter Included |
No |
| Clamping Type |
Band Clamp;U-Bolt Clamp, Band Clamp;U-Bolt Clamp |
| Clamps Included |
Yes, Yes |
| Color/Finish |
Stainless |
| Components |
Band Clamp=4;Bolt=4;Bracket=4;Flange=1;Isolator=2;Nut=2;U-Bolt=1;U-Clamp=1;Washer=4 |
| Country of Origin (Primary) |
US |
| Exhaust Inlet Connection Type |
Bolt-On |
| Exhaust Pipe Material |
Stainless |
| Exhaust Tip Diameter |
3.5, 3.5 |
| Exhaust Tip Finish |
Polished, Polished |
| Exhaust Tip Material |
Stainless Steel, Stainless Steel |
| Exhaust Tip Quantity |
2, 2 |
| Exhaust Type |
Dual |
| Exit Location |
Dual Split Rear |
| Exit Position |
Dual Split Rear |
| Exit Quantity |
Dual |
| Exit Style |
Dual Split Rear |
| Finish |
Stainless, Stainless Steel |
| Gasket Or Seal Included |
No, No |
| Hangers Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Connection Type |
Bolt-On |
| Inlet Inside Diameter |
2.500 in. |
| Inlet Inside Diameter (in.) |
2.5 |
| Inlet Size (in.) |
2.5 |
| Inlet Type |
Bolt-On, Bolt-On |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2.500 in. |
| Main Piping Diameter (in.) |
2.5 |
| Material |
Stainless |
| Mounting Bracket Included |
No, No |
| Muffler Body Diameter |
5.000 in. x 8.000 in. |
| Muffler Body Diameter (in.) |
5 x 8 |
| Muffler Body Finish |
Polished |
| Muffler Body Height |
5.000 in. |
| Muffler Body Height (in.) |
5.000 in. |
| Muffler Body Length |
14.000 in., 14 |
| Muffler Body Length (in.) |
14 |
| Muffler Body Material |
Stainless Steel, Stainless Steel |
| Muffler Body Shape |
Oval |
| Muffler Body Width |
8.000 in. |
| Muffler Body Width (in.) |
8.000 |
| Muffler Configuration |
Center/Dual |
| Muffler Count |
1 |
| Muffler Finish |
Polished |
| Muffler Inlet Diameter |
2.500 in. |
| Muffler Inlet Diameter (in.) |
2.500 |
| Muffler Material |
Stainless Steel |
| Muffler Outlet Diameter |
2.500 in. |
| Muffler Outlet Diameter (in.) |
2.500 |
| Muffler Overall Length |
20.000 in. |
| Muffler Overall Length (in.) |
20.000 in. |
| Muffler Quantity |
1, 1 |
| Muffler Type |
Straight-Through, Straight-Through |
| NAFTA Preference Criterion Code |
B |
| Outlet Outside Diameter |
2.500 in. |
| Outlet Outside Diameter (in.) |
2.5 |
| Outlet Size (in.) |
2.5 |
| Oversize Shipping |
841380004932 |
| Pipe Material |
Stainless Steel, Stainless Steel |
| Recommended Use |
Performance |
| SDR Required Flag |
N |
| Series |
Street, Street |
| Sound Level |
Moderate |
| Subtitle |
Cat-Back |
| Subtitles |
Cat-Back |
| System Type |
Cat Back |
| Tail Pipe Diameter |
2.500 in. |
| Tip Diameter |
3.500 in. |
| Tip Diameter (in.) |
3.5 |
| Tip Finish |
Polished |
| Tip Length |
22.000 in. |
| Tip Length (in.) |
22 |
| Tip Material |
Stainless Steel |
| Tip Quantity |
2 |
| Tip Shape |
Round |
| Tip Size |
3.5 in. |
| Tip Type |
Welded;Single Wall;Angle Cut;Cut Edge |
| Tubing Diameter |
2.500 in. |
| Type |
Cat-Back, Cat-Back |
| Valve Included |
No, No |
| Warranty |
Lifetime |
| Warranty Time |
12 |
| GTIN |
00841380004932 |
