K&N's easy-to-install performance air box replaces the restrictive factory air filter and air intake housing delivering a guaranteed power gain.
The K&N 57S-9501 Performance Airbox is an air intake system that replaces the restrictive factory air filter and air intake assembly. K&N intakes are designed to dramatically reduce air flow restriction as well as smooth and straighten air flow. This allows your engine to inhale a larger amount of air than the factory air filter assembly. More air means more usable power and acceleration throughout the engine's RPM range. The 57S-9501 air intake comes with an oversized cone shaped K&N high-flow air filter, a fully enclosed injection-molded air box, a mandrel-bent aluminum air intake tube and a flexible air intake hose. The aluminum air intake tube is powder coated in a durable textured black finish. The performance air box has a removable lid for easy access to the filter when cleaning is required. The air filter can be used for up to 100,000 miles before servicing is needed depending on driving conditions. This air intake system is relatively easy to install usually in 90 minutes or less using the vehicle's existing factory mounting points with commonly available tools. K&N builds these air intake systems to last for the life of your vehicle. Some K&N 57S Series Performance Airboxes are compliant with the latest TUV emissions and sound regulations. Check the K&N catalog or website for vehicle applications and specific TUV status for each vehicle and air intake.
- Guaranteed to increase horsepower
- Designed to improve torque and acceleration
- Replaces entire factory air intake assembly
- Washable and reusable lifetime air filter
- Easy to install, usually in 90 minutes or less
- Lasts up to 100,000 miles before service is required (depending on driving conditions)
- K&N Million Mile Limited Warranty
Application Summary:
| Year |
Make/Model |
| 2008-2012 |
Audi A3 |
| 2011-2013 |
Audi TT |
| 2010-2014 |
Seat Altea XL |
| 2009-2012 |
Seat Leon |
| 2011-2012 |
Volkswagen Beetle |
| 2013-2015 |
Volkswagen CC |
| 2010 |
Volkswagen Jetta |
| 2009-2010 |
Volkswagen Passat |
| 2010-2012 |
Volkswagen Passat CC |
| 2009-2014 |
Volkswagen Tiguan |
| Attributes |
| ASIN |
B003CR4CPM |
| Air Box Included |
Yes |
| Air Filter Color |
Red |
| Air Filter Element Washable |
Yes |
| Air Filter Height |
6.500 in. (165mm) |
| Air Filter Large End Diameter |
6.000 in. (152mm) |
| Air Filter Material |
Cotton Gauze |
| Air Filter Oulet Length |
4.375 in. (111mm) |
| Air Filter Oulet Width |
4.375 in. (111mm) |
| Air Filter Outlet Length |
4.375 in. (111mm) |
| Air Filter Outlet Shape |
Round |
| Air Filter Outlet Width |
4.375 in. (111mm) |
| Air Filter Washable |
Yes |
| Alternate Part Number |
57S-9501 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| California Restricted |
Not legal for sale or use in California |
| Clamp Color |
Natural |
| Clamp Color/Finish |
Natural |
| Clamp Material |
Steel |
| Clamp Quantity |
3 |
| Clamp Style |
Regular |
| Clamps Included |
3 |
| Country of Origin (Primary) |
US |
| Coupler Color |
Black |
| Coupler Color/Finish |
Black |
| Couplers Included |
1 |
| Emission Code |
Not in CA |
| Filter Color |
Red |
| Filter Material |
Cotton Gauze |
| GTIN |
00024844257178 |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Intake Pipe Color |
Textured Black |
| Intake Pipe Color / Finish |
Textured Black |
| Intake Pipe Inlet Length |
4.375 in. (111mm) |
| Intake Pipe Inlet Shape |
Round |
| Intake Pipe Inlet Width |
4.375 in. (111mm) |
| Intake Pipe Material |
Aluminum |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Item Weight |
5.500 lbs. (2.5 kg) |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mass Air Flow Sensor Included |
Mass Air Flow Sensor Adapter Included When Required |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
Yes, Filter Is Pre-Oiled |
| Package Material |
Paperboard |
| Package Type |
Box |
| Product Box Height |
12 in (305 mm), 12.000 in. (305mm) |
| Product Box Length |
20 in (508 mm), 20.000 in. (508mm) |
| Product Box Width |
12 in (305 mm), 12.000 in. (305mm) |
| Product Style |
57i Series International Kits |
| Replacement Filter |
RU-5061 |
| SDR Required Flag |
N |
| Street Legal |
No |
| Street Legal In All US States |
No, Not legal for sale or use in California on any pollution controlled motor vehicle. |
| TUV Approved (Europe) |
See Application Link Above, See Vehicle Applications, See Application Link Above |
| TUV Certificate Number |
TU-025704-A0-206 |
| Type |
Gen II |
| Warranty |
No-Hassle Lifetime Limited |
| Weight |
5.5 lb (2.5 kg) |
