This K&N NextGen cold air intake system is engineered for Ford F150/Raptor V6 2.7L/3.5L F/I. A high-density polyethylene (HDPE) rotationally molded tube helps increase the volume of airflow by 26.1% CFM GAIN (driver side) & 25.2% CFM GAIN (passenger side) to your engine and provides an increase of 16.2 horsepower and 16.5 torque with no tune required. This intake system is paired with a washable, reusable Dryflow LIFETIME Air Filter featuring an oil-free synthetic media. The oversized, conical design allows you to go up to 50,000 miles between filter services under normal highway driving conditions and has an easy oil-free two step cleaning process for convenience. A custom designed NextGen air box helps protect intake air from the high temperature of your engine bay, and the entire system can typically be installed in less than 60 minutes.
- Dyno-Proven Performance: Dyno-proven to deliver a guaranteed increase in horsepower and torque on your engine's stock tune. Experience the exciting roar of your engine during acceleration, without drone at cruising speeds.
- NextGen Airbox: The hybrid airbox features a semi-enclosed airbox that helps lower air temperatures, an enlarged fresh air inlet for improved airflow, and better protection against contaminants.
- Oversized Dryflow® Filter: Features a radius-entry inlet to increase airflow and performance. NextGen filters also feature Quick-Lock™ technology for fast, secure installation with minimal hardware sealing in place with just one hose clamp.
- Large-Diameter Tube: The large-diameter, CAD-designed intake tube features strategically positioned air channels that increase airflow, boosting airspeed and delivering more air to your engine for added performance.
- Precision Engineering: Each NextGen Dryflow® intake is precisely engineered for your vehicle, enhancing the style of your engine bay while providing exceptional filtration without sacrificing performance.
- Sinister Aesthetic: The all-black design delivers a sleek, stealthy presence with an aggressive black-on-black finish that complements any build and looks just as powerful as it performs.
- Engineered for Convenience: NextGen Dryflow® filters feature an easy, two-step cleaning process that requires no oil, making maintenance more convenient.
Application Summary:
| Year |
Make/Model |
| 2021-2025 |
Ford F-150 |
| Attributes |
| Air Box Included |
Yes |
| Air Filter Color |
Black |
| Air Filter Material |
Non-woven Synthetic |
| Air Filter Outlet Shape |
Round |
| Air Filter Washable |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| California Restricted |
Not legal for sale or use in California |
| Clamp Color/Finish |
Black |
| Clamp Material |
Stainless Steel |
| Clamp Style |
Regular |
| Clamps Included |
5 |
| Country of Origin (Primary) |
US |
| Coupler Color/Finish |
Black |
| Couplers Included |
2 |
| Emission Code |
Not in CA |
| Estimated Horsepower Gain |
16.2 HP @ 5200 RPM |
| Estimated Torque Gain |
16.5LBFT @ 2900RPM |
| GTIN |
00024844418142 |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Intake CFM Gain |
26.1 and 25.2 |
| Intake Pipe Color / Finish |
Black |
| Intake Pipe Material |
High-Density Cross-Linked Polyethylene |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
No |
| Package Material |
Corrugated |
| Package Type |
Box |
| Product Style |
50 Series GEN3 |
| Replacement Filter |
RU-3150HBK |
| SDR Required Flag |
N |
| Street Legal In All US States |
Not legal for sale or use in California on any pollution controlled motor vehicle. |
| TUV Approved (Europe) |
No |
| Warranty |
No-Hassle Lifetime Limited |
| Weight |
13 lb (5.9 kg) |
