This K&N NextGen cold air intake system is engineered for Ford F150/F150 Raptor V6 3.5L. A high-density polyethylene (HDPE) rotationally molded tube helps increase the volume of airflow by 59.01% CFM GAIN (driver side) & 38.3% CFM GAIN (passenger side) to your engine and provides an increase of 32.38 horsepower and 35.52 torque with no tune required. This intake system is paired with a washable, reusable High-Flow LIFETIME Air Filter featuring oiled cotton filter media. The oversized, conical design allows you to go up to 100,000 miles between filter services under normal highway driving conditions. A custom designed NextGen air box helps protect intake air from the high temperature of your engine bay, and the entire system can typically be installed in less than 60 minutes.
- No-Hassle Warranty: NextGen intakes are backed by a Lifetime Limited Warranty and will preserve your factory warranty. Proudly engineered in the USA with dedicated customer support.
- Dyno-Proven Performance: Dyno-proven to deliver a guaranteed increase in horsepower and torque on your engine's stock tune. Experience the exciting roar of your engine during acceleration, without any drone at cruising speeds.
- NextGen Airbox: The hybrid airbox features a semi-enclosed airbox that helps lower air temperatures, an enlarged fresh air inlet for improved airflow, and better protection against contaminants.
- Oversized Air Filter: An oversized air filter features an increased surface area and a radius-entry design, both engineered to increase airflow and enhance performance.
- Large-Diameter Tube: The large-diameter, CAD-designed intake tube features strategically positioned air channels that increase airflow, boosting airspeed and delivering more air to your engine for added performance.
- Precision-Engineering: Each NextGen intake is precisely engineered for your vehicle, enhancing the style of your engine bay while increasing horsepower, torque, and airflow.
- Simplified Installation: The simplified design reduces mounting hardware, while Quick-Lock™ technology allows the filter to snap into place. A sealing bead secures the system with just one hose clamp.
- 50+ Years of Trusted Protection: Since 1969, K&N filters have delivered superior filtration, extended cleaning intervals, and proven performance, trusted by racers and enthusiasts alike.
Application Summary:
| Year |
Make/Model |
| 2017-2020 |
Ford F-150 |
| Attributes |
| Air Box Included |
Yes |
| Air Filter Color |
Red |
| Air Filter Material |
Cotton Gauze |
| Air Filter Outlet Shape |
Round |
| Air Filter Washable |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| California Restricted |
Not legal for sale or use in California |
| Clamp Color/Finish |
Black |
| Clamp Material |
Stainless Steel |
| Clamp Style |
Worm Gear |
| Clamps Included |
5 |
| Country of Origin (Primary) |
US |
| Coupler Color/Finish |
Black |
| Couplers Included |
2 |
| Emission Code |
Not in CA |
| Estimated Horsepower Gain |
32.38 HP @ 5332 RPM |
| Estimated Torque Gain |
35.52LBFT @ 3494RPM |
| GTIN |
00024844416698 |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Intake CFM Gain |
38 |
| Intake Pipe Color / Finish |
Black |
| Intake Pipe Material |
High-Density Cross-Linked Polyethylene |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
Yes |
| Package Material |
Corrugated |
| Package Type |
Box |
| Product Style |
50 Series GEN3 |
| Replacement Filter |
RU-5301 |
| SDR Required Flag |
N |
| Street Legal In All US States |
Not legal for sale or use in California on any pollution controlled motor vehicle. |
| TUV Approved (Europe) |
No |
| Warranty |
No-Hassle Lifetime Limited |
| Weight |
15.6 lb (7.1 kg) |
