Rebuildable and serviceable. Custom valving options available.
FOX devotes countless hours of research and development to design race-winning suspension that withstands incredible punishment and provides consistent performance you can rely on. Regardless of whether you are flying high over the desert or struggling to stick to a rock face on an off-camber climb, our shocks will give you the damping performance, suspension control and proper spring rate to get the job done.
- Packed With 35 Years Of Race Winning Technology
- Brilliant Chrome Plated Seamless Alloy Body
- Chrome Plated Heat Treated Alloy Steel Shaft
- ORB O-Ring Port Fittings Deliver A Superior Seal
- Black Anodized CNC Machined Aluminum Components
- 100% Serviceable And Tunable For Longer Lifespan
- Teflon-Lined Heat-Treated Spherical Bearings
- Redundant Sealing System/Long Lasting Performance
Application Summary:
| Year |
Make/Model |
| 2.0 |
X 6.5 SMOOTH BODY REMOTE-CLASS 11 FRONT (STEM TOP)-5/8in. SHAFT |
| Attributes |
| Adjustable |
No |
| Adjustable Length |
No |
| Body Material |
Steel |
| Bottom Mount |
Eyelet |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length |
11.840 in. |
| Collapsed Length (in.) |
11.840 |
| Color |
Steel |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length |
18.340 in. |
| Extended Length (in.) |
18.340 in. |
| FOX CATALOG |
OFFROAD |
| Finish |
Painted |
| GTIN |
00714686854085 |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Hose Size |
-5AN x 20.000 in. |
| Life Cycle Status Code |
Available to Order |
| Mounting |
12mm x 1.165 |
| NAFTA Preference Criterion Code |
B |
| Reservoir Dimensions |
2.000 in. x 11.000 in. |
| Reservoir Type |
Remote |
| SDR Required Flag |
N |
| Series |
Factory Race |
| Shaft Diameter |
0.625 in. |
| Shock Stroke |
6.500 in. |
| Shock Stroke (in.) |
6.500 |
| Size |
2 in. |
| Top Mount |
Eyelet |
| Type |
Smooth Body Shock |
| Valving |
45/35 |
| Warranty Time |
12 |
