46mm Monotube Shock Absorber
Bilstein B8 5165 Classic remote reservoir shock absorbers are designed to be used on custom off-road vehicles in order to achieve the desired ride of your light truck or SUV. These high gas pressure monotube shock absorbers are sold by various lengths and valve rates to accommodate a wide range of uses and custom applications. All B8 5165 Classic shock absorbers come equipped with 5/8 inch eyelets with hour glass bushings on both ends. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting, providing a clean, low profile installation. B8 5165 Classic cremote reservoir shock absorbers will increase overall durability of your custom vehicle allowing you to conquer the harshest of off-road environments.
- Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
- Remote reservoir increases shock oil capacity for greater heat dissipation
- 46mm monotube design ensures consistent, fade-free performance in all conditions
Application Summary:
| Year |
Make/Model |
| No |
Applications |
| Attributes |
| Adjustable Damping |
Non-Adjustable |
| Body Design |
Smooth Body (Non-Coilover) |
| Body Diameter (ID) |
46mm |
| Boot Included |
No |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Collapsed Length (IN) |
20.65 |
| Collapsed Length (IN) Rounded |
21 |
| Collapsed Length (mm) |
524.5 |
| Compression @0.52m/s |
575 |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Extended Length (IN) |
34.76 |
| Extended Length (IN) Rounded |
35 |
| Extended Length (mm) |
883.0 |
| Finish |
Zinc Plated |
| GTIN |
00651860649702 |
| Harmonized Tariff Code (Schedule B) |
8708800050 |
| Hazardous Material Code |
N |
| Internal Design |
Monotube |
| Life Cycle Status Code |
Superseded |
| Lower Mount Type |
Eye 5/8in |
| Mount Type |
Eye-to-Eye |
| Optional Reservoir Clamp |
11-176015 |
| PartType |
Shocks / Struts |
| Piston Diameter |
46mm |
| Rebound @0.52m/s |
1600 |
| Reservoir |
Yes |
| SDR Required Flag |
Y |
| SDS Sheet Number |
USA SDS_Shock_Air Spring_V2_EN.pdf |
| Segment |
Light Truck |
| Series |
B8 5165 |
| Shaft Diameter |
14mm |
| Spring Max Travel (IN) |
14.11 |
| Spring Seat Included |
No |
| Stroke/Travel Length (IN) |
14.11 |
| Stroke/Travel Length (mm) |
358.4 |
| Upper Mount Type |
Eye 5/8in |
| Warranty Time |
3 |
