Dual-color lamp harness designed for Xtreme Bar Pro, and Work Pod Task. Links up to 4 lamps with a total maximum power of 160W. Features a two-button digital switch. One button cycles through white, amber, and dual-color modes, while the other button activates the amber strobe and allows switching between 5 different strobe patterns. Long-pressing the buttons turns off the lights.
- Control dual-color lamps to switch between different colors and strobe patterns.
- Designed for Xtreme Bar Pro and Work Pod Task only.
- (2) outputs can link up to 4 lamps.
- Power up to 160W of lights.
- Each output can power up to 80W.
- Digital switch included.
- Connector kit included to adapt to different light configurations.
Information:
1 X Connector Kit| Attributes | |
| Average Wattage | 3 |
| California Proposition 65 | No |
| Country of Origin (Primary) | CN |
| Current Draw Per Output@12VDC | 10A |
| Emission Code | Legal US |
| GTIN | 00793888982185 |
| Hazardous Material Code | N |
| IP Rating | IP67 |
| Life Cycle Status Code | Available to Order |
| Maximum Current Draw@12VDC | 20A |
| Maximum Wattage | 6 |
| NAFTA Preference Criterion Code | B |
| Operating Temperature | -40 to 149 |
| SDR Required Flag | N |
| Terminal Type | Blunt Cut |
| Voltage | 10-30V |
| Warranty Time | 2 |
ARC Lighting BB84042 WorkLink™ Universal Dual Color Work Light Harness 2 Lamps (1EA)
Product Information
- Brand: ARC Lighting
- Product Number: BB84042
- Availability: 6 in stock at Main Warehouse
*Allow 2-3 business days to ship to your local H&H store. (In stock items only)
$65.55
Professional Installation +$156.25
