The AIRAID Throttle Body Spacer is designed to enhance mid-range torque using a patented Helix Bore which spins intake air going through the throttle body spacer. Includes mounting hardware.
The AIRAID Throttle Body Spacer is designed to enhance off-idle torque from 800 rpm to approximately 3,000 rpm. The spacer utilizes it's unique, patented Helix Bore design to spin the incoming air charge as it passes through the throttle body spacer. The spinning air action boosts the velocity of the incoming air and contributes to better atomization of the air/fuel mixture as the air charge enters the combustion chamber. The end result is more part-throttle torque and improved mid-range power.
- Made from aircraft quality billet 6061-T6 aluminum
Information:
Aircraft Quality Billet 6061-T6 Aluminum; Improves Low End Torque And Throttle Response; Installs In Less Than 1 Hour; No Drilling Or Cutting Required; Provides Stronger Mid-Range Power; Maximize Fuel Efficiency
Application Summary:
| Year |
Make/Model |
| 2007-2008 |
Chrysler Aspen |
| 2004-2008 |
Dodge Durango |
| 2003-2008 |
Dodge Ram 1500 |
| 2003-2008 |
Dodge Ram 2500 |
| 2003-2008 |
Dodge Ram 3500 |
| Attributes |
| ASIN |
B0007A2APG |
| Alternate Part Number |
AIR-300-577 |
| CARB EO Number |
D-609-3, D-609-3 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
CN |
| Emission Code |
Legal US |
| Finish |
Black |
| GTIN |
00642046305772 |
| Gasket Or Seal Included |
Yes |
| Gaskets Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8481909010 |
| Hazardous Material Code |
N |
| Item Weight |
0.500 lbs. (0.2 kg) |
| Life Cycle Status Code |
Available to Order |
| Material |
Billet Aluminum |
| Material Used |
Billet Aluminum, Billet Aluminum |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Package Material |
Plastic Other |
| Package Type |
Blisterpack |
| Product Box Height |
9.75 in (248 mm), 9.750 in. (248mm) |
| Product Box Length |
6 in (152 mm), 6.000 in. (152mm) |
| Product Box Width |
1.5 in (38 mm) |
| Product Style |
AIRAID PowerAid, AIRAID PowerAid |
| SDR Required Flag |
N |
| Spacer Type |
4-Barrel Open |
| Street Legal |
Yes |
| Street Legal In All US States |
Yes, Legal for use in all 50 states. |
| TUV Approved (Europe) |
No, No |
| Thickness |
1 in (25 mm), 1 in (25 mm) |
| Warranty |
12 Months - 24,000 Miles |
| Weight |
0.5 lb (0.2 kg), 0.5 lb (0.2 kg) |
